Normal and ineffective erythropoiesis
Erythropoiesis is defined as a vital, life-long process where haematopoietic stem cells differentiate and mature into red blood cells.1 Although the erythropoiesis process is continuous, it can be thought of as occurring in two stages: early- versus late-stage erythropoiesis.
Anaemia, a condition that affects almost 25% of the global population, refers to the shortage of functional haemoglobin or reduction in red blood cells.1,2 Anaemia reduces the delivery of oxygen to tissues, which is compensated primarily by increasing cardiac output; the resulting tissue hypoxia can affect the function of major organs.3 Chronic, severe anaemia is associated with increased risk of death due to cardiac failure.4,5 Reduced delivery of oxygen to tissues also causes other symptoms such as fatigue, dyspnoea, tachycardia, hypotension, low body temperature and enlarged spleen.6
The main cause of anaemia is iron deficiency, closely followed by anaemia associated with chronic disease.6 This website will discuss and focus on anaemia associated with haematological diseases.
In anaemia associated with chronic haematological diseases, reduced red blood cell formation may occur due to ineffective erythropoiesis. Ineffective erythropoiesis causes an imbalance in the various progenitor and precursor cells that proliferate, differentiate and mature into red blood cells, leading to impaired erythropoiesis.7‑11 Ineffective erythropoiesis is a hallmark of certain haematological diseases such as:7-10,12-16
Erythropoiesis is defined as a vital, complex, life-long process where haematopoietic stem cells proliferate, differentiate and mature into red blood cells.17 Erythropoiesis is a continuous process of red blood cell formation that can be conceptually divided into early and late stages.18
Erythropoiesis can conceptually be divided into early and late stages.18 The erythroid progenitor cell compartment contains the early erythroid progenitors. BFU-E represent the earliest progenitors committed exclusively to erythroid maturation, which differentiate into late CFU-E and proerythroblasts.19 The earliest recognisable erythroid cells are the Pro‑E, which undergo morphological changes such as reduction in cell size, protein production including haemoglobin, and reduction in proliferative capacity, evolving through the erythroblast stages, Baso‑E, Poly‑E and Ortho‑E, successively.20,21 At the end of the terminal maturation, erythroblasts expel their nuclei and lose all their organelles resulting in mature enucleated cells, called reticulocytes.20 After expelling its nucleus, the reticulocyte is released into the bloodstream where maturation continues in order to produce fully functional, biconcave erythrocytes within 1–2 days.20
Baso‑E, basophilic erythroid; BFU-E, burst-forming unit-erythroid; CFU-E, colony-forming unit-erythroid; Ortho-E, orthochromatophilic; Poly‑E, polychromatophilic; Pro‑E, proerythroblasts; RBC, red blood cell.
The process of erythropoiesis is tightly regulated by many different transcription factors and signalling pathways, as shown in the figure below.13,18,22-30
A complex network of transcription factors and epigenetic regulators ensure appropriate numbers of red blood cells are produced during the process of erythropoiesis.18,31,32 EPO promotes survival and proliferation of erythroid progenitor cells by preventing apoptosis.33 GATA‑1 is the main regulator of lineage-commitment, differentiation and survival of early-stage erythroid cells.18,31 Other transcription factors include regulators of iron metabolism, such as TfR1 and early acting haematopoietic growth factors such as SCF.18 FAS‑L is expressed by late-stage erythroid cells to trigger apoptosis of immature erythroid cells and regulate maturation, while selected TGF‑β superfamily ligands also play a key role in regulating erythroid maturation.18,30,32,34,35 Tight regulation of erythropoiesis is crucial to ensure a steady-state process.18
BMP2, bone morphogenetic protein 2; EPO, erythropoietin; CFU‑E, colony-forming unit-erythroid; EPO‑R, erythropoietin receptor; FAS‑L, FAS ligand; GDF, growth differentiation factor; HSC, haematopoietic stem cells; IL‑3, interleukin 3; IL3-R, interleukin 3 receptor; IgA, immunoglobulin A; SCF, stem cell factor; Tf, transferrin; TfR‑1 (or CD71), transferrin receptor; TGF, transforming growth factor.
Erythropoietin stimulates red blood cell production by acting as a key positive regulator of early-stage erythropoiesis; its greatest influence occurs during the colony-forming unit-erythroid (CFU-E)/proerythroblasts stage of the erythropoiesis process and wanes during the later maturation stages.13,33,36,37 The transcription factor GATA‑2 is highly expressed in haematopoietic stem cells and early-stage progenitors, but its expression is suppressed from the CFU‑E stage and beyond.38 Expression of GATA‑1 is first seen in CFU‑E progenitors and increases as the erythroblasts differentiate and mature. This transition of GATA expression from GATA‑2 to GATA‑1 during the erythropoiesis process, as indicated in the figure above, is referred to as the GATA switch mechanism, and results in the mutually exclusive expression of GATA‑2 and GATA‑1 during early and late stages of erythropoiesis, respectively.23,38 FAS ligand is expressed by late-stage erythroid precursor cells and is involved in regulating the final maturation stages that lead to the formation of functional red blood cells.18 Members of the transforming growth factor β (TGF‑β) superfamily can exert opposing regulatory effects on the erythropoiesis process.30 Signalling mediated by selected TGF‑β superfamily ligands regulates erythroid maturation via the Smad pathway; dysregulation of this signalling pathway may contribute to impaired erythroid maturation leading to ineffective erythropoiesis.34,39,40
In healthy individuals, a normal erythropoiesis process maintains the circulating erythrocyte count within remarkably narrow limits.11,13,33 Successful erythropoiesis is dependent on maintaining a tightly regulated differentiation pathway to retain appropriate levels of erythrocytes. In ineffective erythropoiesis, there is an imbalance in erythropoiesis through increased proliferation of erythroid progenitors accompanied by increased apoptosis and reduced maturation of erythroid precursors.7‑11 Ineffective erythropoiesis is a prominent component of the anaemia that accompanies a range of haematological diseases, including myelodysplastic syndromes, β‑thalassaemia, and congenital dyserythropoietic anaemias.12
Haematological disorders are often associated with alterations in certain signalling pathways that regulate red blood cell formation and result in ineffective erythropoiesis.8,9,11,34,39,41-43 Late-stage erythropoiesis involves the maturation of erythroid cells; a defect at this stage is referred to as an erythroid maturation defect.18,44
Normal erythropoiesis process proceeds with maturation and apoptosis tightly regulated to maintain red blood cell homeostasis and normal oxygen levels. Ineffective erythropoiesis is an ongoing pathological state in which increased erythroid proliferation cannot restore red blood cell count due to increased apoptosis of immature erythroid cells and impaired late-stage maturation.11
Professor Antonis Kattamis, Professor of Pediatric Hematology Oncology, Aghia Sophia Children’s Hospital
In this video, Professor Kattamis describes the pathogenic mechanism of ineffective erythropoiesis that leads to chronic anaemia in patients with β-thalassaemia. Professor Kattamis also outlines the classification and age distribution of patients with the disease.
6-minute video
Professor Olivier Hermine, Professor of Haematology, Paris Necker Children’s Hospital
In this video, Professor Hermine outlines the mechanism of erythropoiesis and explains the importance of erythroid homeostasis, highlighting the regulatory hormones and transcription factors involved.
3-minute video
Additional to the range of symptoms associated with the chronic anaemia seen in haematological diseases, such as cardiac failure, fatigue, dyspnoea, tachycardia, hypotension, low body temperature and enlarged spleen, ineffective erythropoiesis may also cause iron overload, which has its own complications.4,6,44,45 Iron, bound to plasma transferrin, circulates the body and accumulates within cells in the iron-storage protein ferritin. Hepcidin regulates iron metabolism by inhibiting iron absorption in the gut. Ineffective erythropoiesis suppresses hepcidin production in the liver, leading to unrestrained intestinal iron uptake.18,43,46 Additionally, the body attempts to compensate for the haemoglobin shortage by absorbing more iron. Increased iron levels result in saturation of transferrin and, as there is no physiological pathway to excrete iron, non-transferrin-bound iron begins to accumulate in the body. This non-transferrin-bound free iron is toxic, and, as levels in the blood rise, iron deposits in various organs leading to a range of clinical complications including pituitary damage, hyperthyroidism, liver disease, heart failure and diabetes.45,48-54
Ineffective erythropoiesis can also lead to erythroid marrow expansion, which can result in bone deformities in the skull and face, a complication observed in patients with thalassaemias.55,56 Hypercoagulable state, which is linked to a high prevalence of thromboembolic and cerebrovascular events, is also associated with ineffective erythropoiesis.55
Ineffective erythropoiesis contributes to a variety of symptoms and complications that are characteristic of certain haematological disorders.55-57
RBC, red blood cell.
